モデル: Pomalux ® SD-A
ブランド: ポマルクス
| 販売単位 | : | Kilogram |
| パッケージ型式 | : | エクスポートパッケージ |
The file is encrypted. Please fill in the following information to continue accessing it
| DETAIL | |||
| Description | Value | ||
| Material Type | Semi-Crystalline Thermoplastic | ||
| Chemical Name | POM Polyoxymethylene Acetal Copolymer | ||
| Trade Name | Pomalux®SD-A | ||
| Additives | Non Carbon SD Additive | ||
| Color | Natural (Beige) | ||
| Manufacturer | Westlake | ||
| PHYSICAL | |||
| Property | Test | Unit of Measure | Value |
| Density | ASTM D792 | g/cm³ | 1.3 |
| ASTM D792 | lb/in³ | 0.047 | |
| Water Absorption, 24 hrs, Immersion | ASTM D570 | % by wt. | 2.5 |
| MECHANICAL | |||
| Property | Test | Unit of Measure | Value |
| Tensile Strength | ASTM D638 | psi | 6,200 |
| Flexural Strength | ASTM D790 | psi | 8,600 |
| Flexural Modulus | ASTM D790 | psi | 260,000 |
| Hardness | NA | Shore D76 | |
| IZOD Impact-Notched | ASTM D256 | ft-lb/in | 2 |
| THERMAL | |||
| Property | Test | Unit of Measure | Value |
| Coefficient of Linear Thermal Expansion | ASTM D696 | x 10-5 in./in./℉ | 6.5 |
| Heat Deflection Temp | ASTM D648 | ℃ at 264 psi | 89 |
| ASTM D648 | ℉ at 264 psi | 192 | |
| Max Continuous Operating Temp | ℃ | 82 | |
| ℉ | 180 | ||
| Minimum Operating Temp | ℃ | -50 | |
| ℉ | -58 | ||
| Thermal Conductivity | ASTM C117 | BTU-in/ft³-hr-℉ | 2.1 |
| Flammability Rating | UL94 | NA | HB |
| ELECTRICAL | |||
| Property | Test | Unit of Measure | Value |
| Surface Resistivity | ASTM D257 | ohm/square | 10^8 - 10^10 |
