| お支払い方法の種類: | T/T,Paypal |
| インコタームズ: | FOB,CIF,EXW,DDP,DDU |
| 最小注文数: | 1 Kilogram |
| 輸送方法: | Ocean,Land,Air,Express |
| ポート: | Shenzhen,Guangzhou,Hongkong |
モデル: REXOLITE
ブランド: rexolite
原産地: アメリカ
| 販売単位 | : | Kilogram |
| パッケージ型式 | : | 輸出カートンパレット |
| ダウンロード | : |
|
The file is encrypted. Please fill in the following information to continue accessing it
Rexolite®は、ユニークなクロスリンクされたポリスチレンマイクロ波プラスチックです。 Rexolite®は、高周波回路基板、マイクロ波成分、および音響、光学、無線周波数アプリケーションを備えたレンズによく使用されます。元々2つの異なる形式が利用可能でした：Rexolite®1422とRexolite®2200（2200は1422のグラスファイバー強化バージョンです）。
Rexoliteは提供しています：
rexolite®1422シートサイズ
| Thickness (Inch) | Thickness(mm) | Length(mm) | LBS/SQ.FT | KG/㎡ |
| 0.010 | 0.254 |
610 x 610 |
|
|
| 0.015 | 0.381 |
|
|
|
| 0.020 | 0.508 |
|
|
|
| 0.031 | 0.787 |
305 x 305 305 x 610 610 x 610 610 x 1220 915 x 915 |
0.17 | 0.831 |
| 0.046 | 1.168 | 0.26 | 1.270 | |
| 0.062 | 1.575 | 0.34 | 1.661 | |
| 0.093 | 2.362 | 0.51 | 2.492 | |
| 0.125 | 3.175 | 0.68 | 3.322 | |
| 0.187 | 4.750 | 1.02 | 4.984 | |
| 0.250 | 6.350 | 1.36 | 6.645 | |
| 0.375 | 9.525 | 2.05 | 10.016 | |
| 0.500 | 12.700 | 2.72 | 13.290 | |
| 0.625 | 15.875 | 3.41 | 16.661 | |
| 0.750 | 19.050 | 4.10 | 20.032 | |
| 1.000 | 25.400 | 5.40 | 26.384 | |
| 1.250 | 31.750 | 6.80 | 33.224 | |
| 1.500 | 38.100 | 8.20 | 40.065 | |
| 2.000 | 50.800 | 10.90 | 53.257 | |
| 2.500 | 63.500 | 14.00 | 68.403 | |
| 3.000 | 76.200 | 16.00 | 78.175 | |
| 3.500 | 88.900 | 19.00 | 92.833 | |
| 4.000 | 101.600 | 22.00 | 107.491 | |
| 5.000 | 127.000 | 27.00 | 131.921 | |
| 6.000 | 152.400 | 33.00 | 161.236 |
rexolite®1422ロッドサイズ
| Diameter(Inch) | Diameter(Inch) | Diameter（mm） | Length(mm) | LBS/FT | KG/m |
| 1/16" | 0.062 | 1.575 |
1220 1830 2440 3660 |
0.001 | 0.002 |
| 3/32" | 0.093 | 2.362 | 0.003 | 0.005 | |
| 1/8" | 0.125 | 3.175 | 0.006 | 0.008 | |
| 5/32" | 0.156 | 3.962 | 0.009 | 0.013 | |
| 3/16" | 0.187 | 4.750 | 0.013 | 0.019 | |
| 1/4" | 0.250 | 6.350 | 0.022 | 0.033 | |
| 9/32" | 0.281 | 7.137 | 0.028 | 0.042 | |
| 5/16" | 0.312 | 7.925 | 0.035 | 0.052 | |
| 3/8" | 0.375 | 9.525 | 0.050 | 0.074 | |
| 7/16" | 0.437 | 11.100 | 0.068 | 0.101 | |
| 1/2" | 0.500 | 12.700 | 0.089 | 0.132 | |
| 9/16" | 0.562 | 14.275 | 0.110 | 0.164 | |
| 5/8" | 0.625 | 15.875 | 0.140 | 0.208 | |
| 3/4" | 0.750 | 19.050 | 0.200 | 0.298 | |
| 7/8" | 0.875 | 22.225 | 0.270 | 0.402 | |
| 1" | 1.000 | 25.400 | 0.350 | 0.521 | |
| 1-1/8" | 1.125 | 28.575 | 0.450 | 0.670 | |
| 1-1/4" | 1.250 | 31.750 | 0.550 | 0.819 | |
| 1-3/8" | 1.375 | 34.925 | 0.670 | 0.997 | |
| 1-1/2" | 1.500 | 38.100 | 0.790 | 1.176 | |
| 1-5/8" | 1.625 | 41.275 |
1220 2440 |
0.940 | 1.399 |
| 1-3/4" | 1.750 | 44.450 | 1.080 | 1.608 | |
| 1-7/8" | 1.875 | 47.625 | 1.250 | 1.861 | |
| 2" | 2.000 | 50.800 | 1.420 | 2.114 | |
| 2-1/4" | 2.250 | 57.150 | 1.800 | 2.679 | |
| 2-1/2" | 2.500 | 63.500 | 2.210 | 3.290 | |
| 2-3/4" | 2.750 | 69.850 |
306 610 915 1220 |
2.700 | 4.019 |
| 3" | 3.000 | 76.200 | 3.200 | 4.763 | |
| 3-1/4" | 3.250 | 82.550 | 3.700 | 5.508 | |
| 3-1/2" | 3.500 | 88.900 | 4.400 | 6.550 | |
| 3-3/4" | 3.750 | 95.250 | 5.000 | 7.443 | |
| 4" | 4.000 | 101.600 | 5.700 | 8.485 | |
| 4-1/4" | 4.250 | 107.950 | 6.400 | 9.527 | |
| 4-1/2" | 4.500 | 114.300 | 7.200 | 10.717 | |
| 4-3/4" | 4.750 | 120.650 | 8.000 | 11.908 | |
| 5" | 5.000 | 127.000 | 8.900 | 13.248 | |
| 5-1/2" | 5.500 | 139.700 | 10.700 | 15.927 | |
| 6" | 6.000 | 152.400 | 12.700 | 18.904 | |
| 7" | 7.000 | 177.800 | 17.500 | 26.049 | |
| 8" | 8.000 | 203.200 |
305 610 915 |
22.900 | 34.087 |
